SP C360SFNw A4 colour MFP

Prints up to 30 ppm
Single-pass ID copy and scan
7-inch Smart Operation Panel
Mobile printing from smart devices

Configure your device here

A compact workhorse for the busy workplace

Working smart has never been simpler with Ricoh SP C360SFNw, it is more than just a simple multifunction printer. This model comes with an intuitive 7" Smart Operation Panel, which provides both ease-of use and opens up a world of additional functionality. With its fast print speed of 30ppm and first print speed of 7.2 seconds for black and white and 8.6 seconds for colour, it is ideal for any workgroups in need of fast and regular access to printing, copying and scanning. Furthermore, with its compact design, it can be placed on where they are needed most - desktop or counters.

High productivity
Capable of printing at 1,200 x 1,200 dpi, while maintaining high print speeds of 30 ppm, greatly enhancing office productivity.
User-friendly
7-inch Smart Operation Panel
Smart printing
Apple AirPrint^® and Mopria^® support allows users to wirelessly connect and print to these devices from their iOS and Android smartphones respectively.
Eco-friendly
Low power consumption of 1.5 W in Energy Saver Mode (Sleep Mode)

Download PDF brochure

Specifications

Functions: Print, copy, scan, fax
Memory - standard: 2 GB
Operation panel: 7-inch colour touch panel

Physical dimensions (WxDxH)—mainframe: 420 x 540 x 547 mm
Physical dimensions (WxDxH)—other: 400 x 515 x 95 mm—250-sheet paper bank TK1230
400 x 515 x 123 mm—500-sheet paper bank TK1240
Weight—mainframe: 41.5 kg
Weight—other: 5.6 kg or less—250-sheet paper bank TK1230
6.1 kg or less—500-sheet paper bank TK1240

Standard input capacity (sheets)

350

Maximum input capacity (sheets)

850

Standard output capacity (sheets)

150

Supported media

Standard paper input tray and bypass tray
Plain paper, middle thick paper, thick paper 1–2, thin paper, recycled paper, special paper 1–5, colour paper, letterhead, pre-printed paper, bond paper, cardstock, label paper, glossy paper, coated paper, envelopes

Optional paper banks
Plain paper, middle thick paper, thick paper 1–2, thin paper, recycled paper, special paper 1–5, colour paper, letterhead, pre-printed paper, bond paper, cardstock, label paper, glossy paper, coated paper

Paper thickness

56–65 g/m²—thin paper
66–90 g/m²—plain paper
91–128 g/m²—middle thick paper
129–163 g/m²—thick paper 1
164–220 g/m²—thick paper 2
56–90 g/m²—special paper 1
91–163 g/m²—special paper 2
164–220 g/m²—special paper 3
56–90 g/m²—special paper 4
56–90 g/m²—special paper 5

Maximum paper size

A4

Media weight (g/m2)

56–220

Interfaces - standard: 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet)
USB 2.0
USB 2.0 host interface
NFC tag
IEEE 802.11 a/b/g/n (Wireless LAN)
SD card slot
Network protocols - standard: TCP/IP

Copy speed

Single document multiple copy
30 cpm—A4, black and white, and colour

Multiple document single copy—SPDF
28 cpm—A4, black and white, and colour

First copy time

14 seconds or less—black and white
18 seconds or less—colour

Copy resolution

Read
SPDF
300 x 300 dpi, 300 x 600 dpi—colour
300 x 600 dpi—black and white

Platen
300 x 600 dpi, 600 x 600 dpi—colour
600 x 600 dpi—black and white

Write
600 x 600 dpi, 600 x 1,200 dpi equivalent, 600 x 2,400 dpi equivalent, 1,200 x 1,200 dpi

Greyscale

256 levels

Zoom range

25%–400% in 1% steps

Enlargement ratios

141%, 200%

Reduction ratios

93%, 71%, 50%

Copy modes

Text, Photo, Text/Photo, Light background

Duplex copy

Supported

Memory copy

Supported

ID card copy

Supported

Magnification

Directional size magnification

Print speed colour

30 ppm—single-sided
28 ppm—duplex

Print speed black and white

30 ppm—single-sided
28 ppm—duplex

First print time

7.2 seconds or less—black and white, 8.6 seconds or less—colour

Printing process

Electrophotographic printing with LED

Print resolution

600 x 600 dpi
600 x 1,200 dpi equivalent
600 x 2,400 dpi equivalent
1,200 x 1,200 dpi

Page description languages (PDLs)

PCL 5c, PCL 6, PostScript 3 emulation, PDF Direct emulation

Printer drivers

PCL 5c, PCL 6, PostScript 3

Duplex printing

Standard

Mobile printing

Yes

Print from USB/SD

Supported

Non-printable area

4.2 mm—each side

Note: Depends on paper size in edge to edge printing.

Scan speed

Black and white
30 ipm or more—A4 SEF, 200 x 200 dpi, black and white 1-bit, MMR compression with SPDF

Colour
20 ipm or more—A4 SEF, 200 x 200 dpi with full colour letter/photo/JPEG, standard compression with SPDF

Scan resolution

100 x 100 dpi, 200 x 200 dpi (default), 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi

Scan to file types

Single- and multi-page TIFF
Single-page JPEG
Single- and multi-page PDF

Scan to file type support

Single- and multi-page TIFF—compression on
Black and white 1-bit—MH, MR, MMR

Single- and multi-page TIFF—compression off
Black and white 1-bit, black and white greyscale, full colour

Single-page JPEG—compression on
Black and white greyscale, full colour JPEG

Single- and multi-page PDF—compression on/off
Black and white 1-bit, black and white greyscale, full colour

Scan to email

Protocols
POP, SMTP

Authentication
SMTP authentication, POP before SMTP authentication

Scan resolution
100 x 100 dpi, 200 x 200 dpi (default), 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi

Scan to email file types
TIFF, JPEG, PDF—single-page
TIFF, PDF—multi-page

Scan to email—other features

LDAP search
Supported

Maximum email addresses per send
100—via address book
50—manual input

Attention
To, Cc, Bcc

Scan to email size
128 KB—with restriction
42 MB—without restriction

Program user settings
Supported

Divide and send
Supported—if the sent file is larger than the maximum size

Resend
Not supported

Scan to folder

Protocols
SMB

Security
Client folder logon, transmission encryption of logon name and password

Scan resolution
100 x 100 dpi, 200 x 200 dpi (default), 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi

Search for client folders
Supported

Scan to folder file types
TIFF, JPEG, PDF—single-page
TIFF, PDF—multi-page

Scan to folder—other features

Destination folder address input via operation panel
Supported

Maximum client folders/PCs per send
32 folders

Simultaneous transmission
132 maximum destinations

Maximum group addresses
20 destinations

Input file name
Not supported

Maximum file size
42 MB—default
128 KB—when combined with Scan to email

Maximum email addresses per send
32—via address book
32—manual input

Resend
Not supported

TWAIN scanning

Scan mode
Standard, Photo, OCR, Filing

Scan resolution
100 x 100 dpi–600 x 600 dpi in 1 dpi increments

TWAIN scanning—other features

Image adjustment
Brightness, Contrast, Threshold, Gamma Adjustment, Half tone Pattern

Endorse
Date, Page number, Text

Supported operating systems
Windows Server 2008/R2, Windows 7, Windows 8.1, Windows 10, Windows Server 2012/R2, Windows Server 2016

Fax types: G3 fax, LAN-Fax
Fax circuit: PSTN, PBX
Fax compatibilty: ITU-T, G3
Fax scanning speed: 28 spm—A4 SEF, with SPDF
Fax modem speed: 2,400 bps–33.6 Kbps—with Auto Fallback
Fax compression methods: MH, MR, MMR
Fax resolution: 200 x 100 dpi—8 x 3.85 lines/mm
200 x 200 dpi—8 x 7.7 lines/mm
G3 fax transmission speed: 3 seconds approximately—200 x 100 dpi, MMR, ITU-T No. 1 chart, TTI off, memory transmission
Page memory size: 4 MB
Fax SAF memory capacity: 2 MB
Dial features: Redial
Quick dials: 400 numbers

Encryption: Authentication password encryption
Authentication: 802.1x wired authentication
User authentication—Windows and LDAP via Kerberos, basic, user code
Network user authentication
WiFi Protected Setup (WPS)
IEEE 802.11i security (WEP)
Quota setting

Windows

Windows 7
WIndows 8.1
Windows 10
Windows Server 2008
Windows Server 2008 R2
Windows Server 2012
Windows Server 2012 R2
Windows Server 2016

Macintosh

Mac OS X Native v10.8 or later

Unix

Sun Solaris—9, 10
HP-UX—11.x, 11iv2, 11iv3
Red Hat Linux—Enterprise v4, v5, v6
SCO OpenServer—v5.0.7, v6.0
IBM AIX—5L v5.3, v6.1, v7.1

SAP

Environment—R/3, S/4
Platform—SAP R/3 3.0 and later, SAP R/3 Enterprise, mySAP ERP (2004 and later), SAP HANA
Page Description Language (PDL)—PCL
Character set—Latin-1, Latin-2, Unicode
Barcode fonts—Code 128, Code 39, Code 93, 2 of 5, Datamatrix, QR, PDF417

Supported languages

Operation panel
English, German, French, Italian, Spanish, Dutch, Russian, Swedish, Danish, Portuguese, Norwegian, Czech, Hungarian, Turkish, Polish, Finnish, Catalan, Greek, Brazilian Portuguese, Simplified Chinese, Traditional Chinese, Korean

Printer drivers
PCL 5c
English, German, French, Italian, Spanish, Dutch, Russian, Swedish, Danish, Portuguese, Norwegian, Czech, Hungarian, Turkish, Polish, Finnish, Catalan, Simplified Chinese, Traditional Chinese

PCL 6
English, German, French, Italian, Spanish, Dutch, Russian, Swedish, Danish, Portuguese, Norwegian, Czech, Hungarian, Turkish, Polish, Finnish, Catalan, Greek, Brazilian Portuguese, Simplified Chinese, Traditional Chinese

Test page print configuration map
English, German, French, Italian, Spanish, Dutch, Russian, Swedish, Danish, Portuguese, Norwegian, Czech, Hungarian, Turkish, Polish, Finnish, Catalan, Greek, Brazilian Portuguese

Test page print excluding configuration map
English

Standard: Web Image Monitor
Optional: @Remote Office
Device Manager NX
Printer Driver Packager NX
Mobile apps: Smart Device Connector

Power source: 220–240 V, 50/60 Hz
Power consumption: 1,200 W or less—maximum power
469 W—operating, black and white
512 W—operating, colour
43.6 W—Ready Mode
1.5 W—Energy Saver Mode (Sleep Mode)
1.6 W or less—Auto off
25 W or less—Fusing unit off
Typical Electricity Consumption (TEC): 1.3 kWh
Warm-up time: 25 seconds or less
Power saving mode: 1 minute shift time—Auto off
Inactive by default—Fusing unit off
Recovery time: 10 seconds or less—Auto off
10 seconds or less—Fusing unit off
Reduction of environmentally sensitive materials: RoHS
Lead, cadmium, mercury
Environmental standards: RoHS
WEEE
Energy saving standards: Energy Star v2.0
Green labels: Energy Efficiency labelling scheme (Hong Kong), Blue Angel Mark (BAM), Thai Green Label, EcoLogo
Safety standards: EN60950-1 (TUV-SUD)
IEC60950-1 (CB)
IEC60950-1 (EAC Mark/CU-TR)
Electromagnetic Compatibility (EMC) standards: Electromagnetic Interference (EMI) standards
EMC
Australia/NZ EMC (RCM Mark)
EN62311
EAC Mark (CU-TR)
Identification of plastic components: All plastic components that weigh more than 25 g are identified in accordance with DIN 54840 and ISO 11469 standards.
