SP C360SFNw A4 colour MFP
- Prints up to 30 ppm
- Single-pass ID copy and scan
- 7-inch Smart Operation Panel
- Mobile printing from smart devices
A compact workhorse for the busy workplace
Working smart has never been simpler with Ricoh SP C360SFNw, it is more than just a simple multifunction printer. This model comes with an intuitive 7" Smart Operation Panel, which provides both ease-of use and opens up a world of additional functionality. With its fast print speed of 30ppm and first print speed of 7.2 seconds for black and white and 8.6 seconds for colour, it is ideal for any workgroups in need of fast and regular access to printing, copying and scanning. Furthermore, with its compact design, it can be placed on where they are needed most - desktop or counters.
- High productivity
Capable of printing at 1,200 x 1,200 dpi, while maintaining high print speeds of 30 ppm, greatly enhancing office productivity. - User-friendly
7-inch Smart Operation Panel - Smart printing
Apple AirPrint® and Mopria® support allows users to wirelessly connect and print to these devices from their iOS and Android smartphones respectively. - Eco-friendly
Low power consumption of 1.5 W in Energy Saver Mode (Sleep Mode)
Specifications
- Functions
- Print, copy, scan, fax
- Memory - standard
- 2 GB
- Operation panel
- 7-inch colour touch panel
- Physical dimensions (WxDxH)—mainframe
- 420 x 540 x 547 mm
- Physical dimensions (WxDxH)—other
- 400 x 515 x 95 mm—250-sheet paper bank TK1230
400 x 515 x 123 mm—500-sheet paper bank TK1240 - Weight—mainframe
- 41.5 kg
- Weight—other
- 5.6 kg or less—250-sheet paper bank TK1230
6.1 kg or less—500-sheet paper bank TK1240
- Standard input capacity (sheets)
- 350
- Maximum input capacity (sheets)
- 850
- Standard output capacity (sheets)
- 150
- Supported media
Standard paper input tray and bypass tray
Plain paper, middle thick paper, thick paper 1–2, thin paper, recycled paper, special paper 1–5, colour paper, letterhead, pre-printed paper, bond paper, cardstock, label paper, glossy paper, coated paper, envelopesOptional paper banks
Plain paper, middle thick paper, thick paper 1–2, thin paper, recycled paper, special paper 1–5, colour paper, letterhead, pre-printed paper, bond paper, cardstock, label paper, glossy paper, coated paper- Paper thickness
- 56–65 g/m²—thin paper
66–90 g/m²—plain paper
91–128 g/m²—middle thick paper
129–163 g/m²—thick paper 1
164–220 g/m²—thick paper 2
56–90 g/m²—special paper 1
91–163 g/m²—special paper 2
164–220 g/m²—special paper 3
56–90 g/m²—special paper 4
56–90 g/m²—special paper 5 - Maximum paper size
- A4
- Media weight (g/m2)
- 56–220
- Interfaces - standard
- 10Base-T/100Base-Tx/1000Base-T (Gigabit Ethernet)
USB 2.0
USB 2.0 host interface
NFC tag
IEEE 802.11 a/b/g/n (Wireless LAN)
SD card slot - Network protocols - standard
- TCP/IP
- Copy speed
Single document multiple copy
30 cpm—A4, black and white, and colourMultiple document single copy—SPDF
28 cpm—A4, black and white, and colour- First copy time
14 seconds or less—black and white
18 seconds or less—colour- Copy resolution
Read
SPDF
300 x 300 dpi, 300 x 600 dpi—colour
300 x 600 dpi—black and whitePlaten
300 x 600 dpi, 600 x 600 dpi—colour
600 x 600 dpi—black and whiteWrite
600 x 600 dpi, 600 x 1,200 dpi equivalent, 600 x 2,400 dpi equivalent, 1,200 x 1,200 dpi- Greyscale
- 256 levels
- Zoom range
- 25%–400% in 1% steps
- Enlargement ratios
- 141%, 200%
- Reduction ratios
- 93%, 71%, 50%
- Copy modes
- Text, Photo, Text/Photo, Light background
- Duplex copy
- Supported
- Memory copy
- Supported
- ID card copy
- Supported
- Magnification
- Directional size magnification
- Print speed colour
- 30 ppm—single-sided
28 ppm—duplex - Print speed black and white
- 30 ppm—single-sided
28 ppm—duplex - First print time
- 7.2 seconds or less—black and white, 8.6 seconds or less—colour
- Printing process
- Electrophotographic printing with LED
- Print resolution
- 600 x 600 dpi
600 x 1,200 dpi equivalent
600 x 2,400 dpi equivalent
1,200 x 1,200 dpi - Page description languages (PDLs)
- PCL 5c, PCL 6, PostScript 3 emulation, PDF Direct emulation
- Printer drivers
- PCL 5c, PCL 6, PostScript 3
- Duplex printing
- Standard
- Mobile printing
- Yes
- Print from USB/SD
- Supported
- Non-printable area
4.2 mm—each side
Note: Depends on paper size in edge to edge printing.
- Scan speed
Black and white
30 ipm or more—A4 SEF, 200 x 200 dpi, black and white 1-bit, MMR compression with SPDFColour
20 ipm or more—A4 SEF, 200 x 200 dpi with full colour letter/photo/JPEG, standard compression with SPDF- Scan resolution
- 100 x 100 dpi, 200 x 200 dpi (default), 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi
- Scan to file types
Single- and multi-page TIFF
Single-page JPEG
Single- and multi-page PDF- Scan to file type support
Single- and multi-page TIFF—compression on
Black and white 1-bit—MH, MR, MMRSingle- and multi-page TIFF—compression off
Black and white 1-bit, black and white greyscale, full colourSingle-page JPEG—compression on
Black and white greyscale, full colour JPEGSingle- and multi-page PDF—compression on/off
Black and white 1-bit, black and white greyscale, full colour- Scan to email
Protocols
POP, SMTPAuthentication
SMTP authentication, POP before SMTP authenticationScan resolution
100 x 100 dpi, 200 x 200 dpi (default), 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpiScan to email file types
TIFF, JPEG, PDF—single-page
TIFF, PDF—multi-page- Scan to email—other features
LDAP search
SupportedMaximum email addresses per send
100—via address book
50—manual inputAttention
To, Cc, BccScan to email size
128 KB—with restriction
42 MB—without restrictionProgram user settings
SupportedDivide and send
Supported—if the sent file is larger than the maximum sizeResend
Not supported- Scan to folder
Protocols
SMBSecurity
Client folder logon, transmission encryption of logon name and passwordScan resolution
100 x 100 dpi, 200 x 200 dpi (default), 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpiSearch for client folders
SupportedScan to folder file types
TIFF, JPEG, PDF—single-page
TIFF, PDF—multi-page- Scan to folder—other features
Destination folder address input via operation panel
SupportedMaximum client folders/PCs per send
32 foldersSimultaneous transmission
132 maximum destinationsMaximum group addresses
20 destinationsInput file name
Not supportedMaximum file size
42 MB—default
128 KB—when combined with Scan to emailMaximum email addresses per send
32—via address book
32—manual inputResend
Not supported- TWAIN scanning
Scan mode
Standard, Photo, OCR, FilingScan resolution
100 x 100 dpi–600 x 600 dpi in 1 dpi increments- TWAIN scanning—other features
Image adjustment
Brightness, Contrast, Threshold, Gamma Adjustment, Half tone PatternEndorse
Date, Page number, TextSupported operating systems
Windows Server 2008/R2, Windows 7, Windows 8.1, Windows 10, Windows Server 2012/R2, Windows Server 2016
- Fax types
- G3 fax, LAN-Fax
- Fax circuit
- PSTN, PBX
- Fax compatibilty
- ITU-T, G3
- Fax scanning speed
- 28 spm—A4 SEF, with SPDF
- Fax modem speed
- 2,400 bps–33.6 Kbps—with Auto Fallback
- Fax compression methods
- MH, MR, MMR
- Fax resolution
- 200 x 100 dpi—8 x 3.85 lines/mm
200 x 200 dpi—8 x 7.7 lines/mm - G3 fax transmission speed
- 3 seconds approximately—200 x 100 dpi, MMR, ITU-T No. 1 chart, TTI off, memory transmission
- Page memory size
- 4 MB
- Fax SAF memory capacity
- 2 MB
- Dial features
- Redial
- Quick dials
- 400 numbers
- Encryption
- Authentication password encryption
- Authentication
- 802.1x wired authentication
User authentication—Windows and LDAP via Kerberos, basic, user code
Network user authentication
WiFi Protected Setup (WPS)
IEEE 802.11i security (WEP)
Quota setting
- Windows
Windows 7
WIndows 8.1
Windows 10
Windows Server 2008
Windows Server 2008 R2
Windows Server 2012
Windows Server 2012 R2
Windows Server 2016- Macintosh
- Mac OS X Native v10.8 or later
- Unix
- Sun Solaris—9, 10
HP-UX—11.x, 11iv2, 11iv3
Red Hat Linux—Enterprise v4, v5, v6
SCO OpenServer—v5.0.7, v6.0
IBM AIX—5L v5.3, v6.1, v7.1 - SAP
Environment—R/3, S/4
Platform—SAP R/3 3.0 and later, SAP R/3 Enterprise, mySAP ERP (2004 and later), SAP HANA
Page Description Language (PDL)—PCL
Character set—Latin-1, Latin-2, Unicode
Barcode fonts—Code 128, Code 39, Code 93, 2 of 5, Datamatrix, QR, PDF417- Supported languages
Operation panel
English, German, French, Italian, Spanish, Dutch, Russian, Swedish, Danish, Portuguese, Norwegian, Czech, Hungarian, Turkish, Polish, Finnish, Catalan, Greek, Brazilian Portuguese, Simplified Chinese, Traditional Chinese, Korean
Printer drivers
PCL 5c
English, German, French, Italian, Spanish, Dutch, Russian, Swedish, Danish, Portuguese, Norwegian, Czech, Hungarian, Turkish, Polish, Finnish, Catalan, Simplified Chinese, Traditional ChinesePCL 6
English, German, French, Italian, Spanish, Dutch, Russian, Swedish, Danish, Portuguese, Norwegian, Czech, Hungarian, Turkish, Polish, Finnish, Catalan, Greek, Brazilian Portuguese, Simplified Chinese, Traditional Chinese
Test page print configuration map
English, German, French, Italian, Spanish, Dutch, Russian, Swedish, Danish, Portuguese, Norwegian, Czech, Hungarian, Turkish, Polish, Finnish, Catalan, Greek, Brazilian Portuguese
Test page print excluding configuration map
English
- Standard
- Web Image Monitor
- Optional
- @Remote Office
Device Manager NX
Printer Driver Packager NX - Mobile apps
- Smart Device Connector
- Power source
- 220–240 V, 50/60 Hz
- Power consumption
- 1,200 W or less—maximum power
469 W—operating, black and white
512 W—operating, colour
43.6 W—Ready Mode
1.5 W—Energy Saver Mode (Sleep Mode)
1.6 W or less—Auto off
25 W or less—Fusing unit off - Typical Electricity Consumption (TEC)
- 1.3 kWh
- Warm-up time
- 25 seconds or less
- Power saving mode
- 1 minute shift time—Auto off
Inactive by default—Fusing unit off - Recovery time
- 10 seconds or less—Auto off
10 seconds or less—Fusing unit off - Reduction of environmentally sensitive materials
- RoHS
Lead, cadmium, mercury - Environmental standards
- RoHS
WEEE - Energy saving standards
- Energy Star v2.0
- Green labels
- Energy Efficiency labelling scheme (Hong Kong), Blue Angel Mark (BAM), Thai Green Label, EcoLogo
- Safety standards
- EN60950-1 (TUV-SUD)
IEC60950-1 (CB)
IEC60950-1 (EAC Mark/CU-TR) - Electromagnetic Compatibility (EMC) standards
- Electromagnetic Interference (EMI) standards
EMC
Australia/NZ EMC (RCM Mark)
EN62311
EAC Mark (CU-TR) - Identification of plastic components
- All plastic components that weigh more than 25 g are identified in accordance with DIN 54840 and ISO 11469 standards.
