IM C8000 A3 colour MFP
- Copy, print, scan, optional fax
- Prints up to 80 ppm
- 8,100-sheet max input
- Continuous updates via RICOH Always Current Technology
Save on future investments with our future-proofed solutions
RICOH IM C8000, a full colour multi function printer, offers a range of smart applications, enhancements and software to manage your document needs as they change without the need to purchase new equipment. Simply install new features as needed with RICOH Always Current Technology.
Gain even greater control of print and scan management
The additional features you will find on RICOH IM C8000 give you so many more printing options. Scan smaller sized documents with ease with the new small-sized paper scan unit and improve scanning accuracy by simply adding an extra double feed detection unit. You can also create and print professional-grade flyers any time with our new multi-folding unit and save on outsourced printing costs.
- Place personalisation at your fingertips
Perform everyday tasks with speed and precision via the large 10.1'' LCD touch screen. - Convenient finishing options
Create professional publications instantly with out high-speed duplex feeder and additional fold, staple, hole punch and booklet making options. - Digitise documents for speed of access
Scan documents at high speeds and distribute them digitally with a single touch. - Add those colourful finishing touches
Give ideas a fresh look with fast, colourful output and use the multiple finishing options available for direct mail, presentations, menus and so much more.
Specifications
- Functions
- Copy, print, scan, optional fax
- HDD
- 640 GB (320 GB x 2)
- Memory - standard
- 4 GB
- Operation panel
- 10.1-inch Smart Operation Panel (G2.5)
- Physical dimensions (WxDxH)—mainframe
- 750 x 880 x 1,225 mm
- Physical dimensions (WxDxH)—other
- 869 x 730 x 658 mm—2,200-sheet LCT RT4070
352 x 540 x 625 mm—4,400-sheet LCT RT4060
520 x 514 x 207 mm—A3 Tray Type M26
350 x 513 x 192 mm—Copy Tray Type M42
540 x 600 x 660 mm—9-bin Mailbox CS4010
218 x 173 x 55 mm—Small Paper Feeding Unit Type M37
657 x 730 x 980 mm—2,000-sheet Booklet Finisher SR4160
657 x 730 x 980 mm—3,000-sheet Finisher SR4150
806 x 730 x 980 mm—3,000-sheet Finisher SR4140
209 x 730 x 980 mm—Multi-Folding Unit FD4010
470 x 730 x 980 mm—Multi-Folding Unit FD4020
540 x 730 x 1,270 mm—Cover Interposer CI4050
500 x 600 x 600 mm—Cover Interposer CI4040
143 x 539 x 218 mm—Output Jogger Type M25 - Weight—mainframe
- 250 kg or less
- Weight—other
- 83 kg or less—2,200-sheet LCT RT4070
21.3 kg or less—4,400-sheet LCT RT4060
11 kg—A3 Tray Type M26
2.2 kg or less—Copy Tray Type M42
15 kg or less—9-bin Mailbox CS4010
0.19 kg—Small Paper Feeding Unit Type M37
58 kg or less—2,000-sheet Booklet Finisher SR4160
61 kg or less—2,000-sheet Booklet Finisher SR4160 with punch unit
38 kg or less—3,000-sheet Finisher SR4150
41 kg or less—3,000-sheet Finisher SR4150 with punch unit
77 kg or less—3,000-sheet Finisher SR4140
45 kg or less—Multi-Folding Unit FD4010
92 kg—Multi-Folding Unit FD4020
45 kg or less—Cover Interposer CI4050
12 kg or less—Cover Interposer CI4040
2 kg or less—Output Jogger Type M25
- Standard input capacity (sheets)
- 3,700
- Maximum input capacity (sheets)
- 8,100
- Maximum output capacity (sheets)
- 3,500
- Supported media
Plain paper1, recycled paper, colour paper, special paper 1–3, letterhead, pre-printed paper, pre-punched paper, bond paper, card stock, thin paper, plain paper 1–2, middle thick, thick paper 1–4
1—Not displayed as paper type- Paper thickness
- 52.3–65.9 g/m2—thin paper
66–80.9 g/m2—plain paper 1
81–100.9 g/m2—plain paper 2
101–127.4 g/m2—middle thick paper
127.5–150 g/m2—thick paper 1
150.1–216 g/m2—thick paper 2
216.1–256 g/m2—thick paper 3
256.1–300 g/m2—thick paper 4 - Maximum paper size
- 13" x 19.2"
- Media weight (g/m2)
- 52.3–300
- Interfaces - standard
- Mainframe
10Base-T/100Base-TX/1000Base-T (Gigabit Ethernet)
USB Host Type A—2 ports
USB Device Type B—1 port
Smart Operation Panel
IEEE 802.11 b/g/n (Wireless LAN)1
Bluetooth 4.22
SD Card Slot—SDHC memory card
USB Host Type A—USB Flash memory
USB Host Type A—1 port for USB keyboard (optional)2
USB Host Type mini B—for NFC card reader (optional)2
microSD card slot—ROM storage expansion2
NFC Tag2
1—Limited printing for a peer-to-peer mobile device via RICOH Smart Device Connector
2—Cannot be used for printing - Interfaces - optional
IEEE 1284
Wireless LAN (IEEE 802.11 a/b/g/n)1
Device Server Option Type M37 (additional NIC port)
Copy Connector Type M25
1—Cannot be used with Bluetooth at the same time- Network protocols - standard
- TCP/IP (IPv4, IPv6)
- Copy speed
- 80 cpm
- First copy time
- 4.8 seconds—black and white
6.4 seconds—colour - Copy resolution
- 600 x 600 dpi
- Maximum size
- 323 x 480 mm
- Zoom range
- 25%–400% in 1% steps
- Enlargement ratios
- 400%, 200%, 141%, 122%, 115%
- Reduction ratios
- 93%, 82%, 75%, 71%, 65%, 50%, 25%
- Duplex copy
- Simplex to duplex, duplex to duplex—with SPDF, book to duplex, front and back to duplex
- Book copy
- Booklet, magazine, layout, and booklet
- ID card copy
- Supported
- Magnification
- Directional magnification, Directional size magnification
- Punch
- Supported—with finisher
- Print speed colour
- 80 ppm
- Print speed black and white
- 80 ppm
- First print time
- 4.8 seconds or less—black and white; 6.4 seconds or less—colour
- Printing process
- 4-drum dry electrostatic transfer system with internal transfer belt
- Print resolution
- 1,200 x 4,800 dpi—when printing
2,400 x 4,800 dpi—when copying - Page description languages (PDLs)
Standard
PCL 5c, PCL 6, PostScript3 emulation, PDF Direct emulationOptional
Adobe PostScript 3, Adobe PDF Direct, XPS, IPDS- Printer drivers
Standard
PCL 5c, PCL 6, PostScript3 emulation
Optional
Adobe PostScript 3- Duplex printing
- Standard
- Mobile printing
- AirPrint, Mopria®, RICOH Smart Device Connector
- Print from USB/SD
- Supported
- Maximum printable area
- 323 x 480 mm
- Scan speed
- A4 LEF via SPDF
120 ipm—simplex
240 ipm—duplex - Scan methods
- Scan to USB/SD, Scan to email, Scan to folder (SMB, FTP), Scan to URL, Scan to PDF/A, Scan to digitally signed PDF, Scan to searchable PDF (embedded)
- Scan resolution
- 100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi, 1,200 dpi
- Scan to file types
- Single- and multi-page TIFF
Single-page JPEG
Single- and multi-page PDF, PDF/A
Single- and multi-page High-Compression PDF - Scan to file type support
- Single- and multi-page TIFF
Black and white 1-bit—MH, MR, MMR—compression on
Black and white 1-bit, black and white greyscale, full colour—compression off
Single-page JPEG
Black and white greyscale, full colour—compression on
Single- and multi-page PDF, PDF/A
Black and white 1-bit—MH, MR, MMR, JBIG2, black and white greyscale JPEG, full colour JPEG—compression on
Black and white 1-bit, black and white greyscale, full colour—compression off
Single- and multi-page High-Compression PDF
Black and white greyscale, full colour JPEG, JPEG 2000—compression on - Scan to email
Protocols
SMTP gateway, TCP/IP
Authentication
SMTP authentication, POP before SMTP authentication
Scan resolution
100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi
Scan to email file types
Single-page
TIFF, JPEG, PDF, PDF/A, High-Compression PDF, Encrypted PDF, Searchable PDF
Multi-page
TIFF, PDF, PDF/A, High-Compression PDF, Encrypted PDF, Searchable PDF
Note: Optional OCR unit is required to support scanning to a searchable PDF.- Scan to email—other features
Scan to email size
128–102,400 KB—with restriction
700 MB—without restrictionMaximum email addresses per send
500—from HDD
100—direct input
100—via LDAP
Email addresses stored in HDD
Maximum email addresses—2,000
Maximum registered group addresses—100 groups, 500 addresses per group
Maintain email addresses—via operation panel, SmartDeviceMonitor for Admin, Web Image Monitor
Search method—by name, email address
Body message
Manual input—maximum 80 characters via operation panel
User pre-registered—maximum 400 characters, 80 characters over 5 lines
Preset message—This e-mail includes attached file sent from <device name>.
Input subject
Manual input—maximum 128 characters
User pre-registered—maximum 20 characters via soft key
LDAP search
Supported
Input file name
Supported
Simultaneous transmission
Maximum 550 destinations
Attention
To, Cc, Bcc
Program registration
Up to 25 programs
Divide and send
Divide by page or size; default divide by size
Note: If the sent file is larger than the email size restriction, it will be divided into multiple sends. The size restrictions of the email recipient may also impact the send.
Resend
Yes—default/No- Scan to folder
Protocols
SMB, FTP, WSD (Web Services on Devices for Scanning), DSM
Security
Client folder logon, transmission encryption of logon name and password
Resolution
100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi
Search for client folders
SMB—browsing directly to the designated folder
FTP—by folder name
Scan to folders file types
Single-page
TIFF, JPEG, PDF, PDF/A, High-Compression PDFMulti-page
TIFF, PDF, PDF/A, High-Compression PDF- Scan to folder—other features
Client folder addresses stored in HDD
Maximum registered folder addresses—2,000
Maintain folder addresses via operation panel, SmartDeviceMonitor for Admin, Web Image Monitor
Destination folder address input via operation panel
Supported
Homefolder over LDAP
Supported
Maximum client folders/PCs per send
50 folders
Simultaneous transmission
550 destinations maximum when combined with Scan to email
Maximum group addresses
100 destinations from a maximum of 50 folders, 500 email addresses maximum per group
Input file name
Supported
Maximum file size
Default
2,000 MB
When combined with Scan to email
128–102,400 KB; default 2,048 KB—with restriction
725 MB—without restriction
Note: File size depends on the selected Scan to email file size restriction.
Program user settings
Up to 25 programs
Resend
Yes—default/No- TWAIN scanning
- Scan mode
Standard, Photo, OCR, Filing
Scan resolution
100–1,200 dpi - TWAIN scanning—other features
- Scan speed—200 dpi
Black and white
115 ipm—simplex
205 ipm—duplex
Colour
115 ipm—simplex
204 ipm—duplex
Image adjustment
Brightness, Contrast, Threshold, Gamma Adjustment, Halftone Pattern
Endorse
Supported
Stamp originals
Date, Page number, Text
Supported operating systems
Windows 7, Windows 8.1, Windows 10, Windows Server 2008, Windows 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
- Fax types
- G3 fax, Internet fax (T.37), IP fax (T.38), LAN-Fax, Paperless fax, Direct SMTP fax
- Fax circuit
- PSTN, PBX
- Fax compatibilty
- ITU-T (CCITT), G3—maximum 3 lines
- Fax scanning speed
- 75 spm—A4 SEF
94 spm—A4 LEF, Standard Mode
79 spm—A4 LEF, Detail Mode
38 spm—A4 LEF, Super Fine Mode - Fax modem speed
- 2,400 bps–33.6 Kbps—G3, standard with automatic shift down
- Fax compression methods
- MH, MR, MMR, JBIG
- Fax resolution
Standard mode
200 x 100 dpi—8 x 3.85 lines/mm
Detail mode
200 x 200 dpi—8 x 7.7 lines/mm
Super fine mode
400 x 400 dpi—8 x 15.4 lines/mm
400 x 400 dpi—16 x 15.4 lines/mmNote: Super fine mode is supported with the optional SAF memory.
- G3 fax transmission speed
- 2 seconds approximately—JBIG, ITU-T No. 1 chart, TTI off, memory transmission
3 seconds approximately—MMR, ITU-T No. 1 chart, TTI off, memory transmission - Page memory size
- Standard—4 MB
With optional SAF memory—8 MB - Fax SAF memory capacity
- Standard—4 MB
With optional SAF memory—60 MB - Quick dials
- 2,000 numbers
- DataOverwriteSecurity System (DOSS) – Standard
- Yes
- DataOverwriteSecurity System (DOSS) – Optional
- Type M19—available for customers who require their devices to comply with ISO 15408 Common Criteria certification
- Encryption
- PDF, Secure print, WEP, WPA encryption
Authentication password encryption
Encryption of data sent via Scan to email and Fax forwarding (S/MIME) - Authentication
- 802.1x wired authentication
IEEE 802.11i security (WEP, WPA)
IPv6
Network user authentication
Quota setting/Account limit
User authentication—Windows and LDAP via Kerberos, basic, user code
User code authentication
Wi-Fi Protected Setup (WPS) support
- Windows
- Windows 7
Windows Server 2008
Windows Server 2008 R2
Windows 8.1
Windows Server 2012
Windows Server 2012 R2
Windows 10
Windows Server 2016
Windows Server 2019 - Macintosh
- OS X Native v10.12 or later—PostScript 3 only
- Unix
- Sun Solaris—10
HP-UX—11.x, 11iv2, 11iv3
Red Hat Linux—Enterprise v4, v5, v6
SCO OpenServer—5.0.7, 6.0
IBM AIX—6.1, 7.1, 7.2 - SAP
- Environment—R/3, S/4
Platform—SAP R/3 (Release versions 3.0 and higher), SAP R/3 Enterprise, mySAP ERP (2004 and higher), SAP HANA
Page Description Language (PDL)—PCL
Character set—Latin-1, Latin-2, Unicode
Barcode fonts—Code 128, Code 39, Code 93, Codabar, 2 of 5 interleaved/Industrial/Matrix, MSI, USPS Postnet, UPC/EAN
OCR fonts—OCR A, OCR B
Other supported features—Input/Output Bin, Duplex, Stapling, Punching, Resolution, Collation, EconoMode / TonerSaving, Smoothing, Page Protect, Auto Tray Change/Optional Tray Select, User Authentication - Supported languages
- Operation panel
Japanese, English, French, German, Italian, Spanish, Dutch, Norwegian, Danish, Swedish, Polish, Portuguese, Hungarian, Czech, Finnish, Simplified Chinese, Traditional Chinese, Russian, Greek, Catalan, Turkish, Brazilian Portuguese, Korean, Thai
- Standard
- @Remote Embedded
Web Image Monitor - Optional
- @Remote Office
@Remote Enterprise Pro
Global Scan NX
Card Authentication Package
Enhanced Locked Print NX
Device Manager NX Lite
Device Manager NX Accounting
RICOH Streamline NX - Mobile apps
- RICOH Smart Device Connector
- Power source
- 220–240 V, 12–10 A, 50/60 Hz
- Power consumption
- 2,400 W or less—maximum power
1,324.7 W or less—operating power, black and white
1,473.7 W or less—operating power, colour
191.45 W—Ready Mode
170 W—Low Power Mode
0.74 W—Energy Saver Mode (Sleep Mode) - Typical Electricity Consumption (TEC)
- 1.651 kWh (nominal), 2.049 kWh (guaranteed)
- Warm-up time
- 40 seconds
- Power saving mode
- 45 minutes shift time—Energy Saver Mode (Sleep Mode)
15 minutes shift time—Low Power Mode - Recovery time
- 38 seconds—Energy Save Mode (Sleep Mode)
7.9 seconds—Low Power Mode - Safety standards
- EN60950-1
EN62368-1 - Identification of plastic components
- All plastic components are identified in accordance with ISO 11469 standard.
- Other environmental features
- Eco-friendly indicator screen, System reset timer
