    IM C8000 A3 colour MFP

    • Copy, print, scan, optional fax
    • Prints up to 80 ppm
    • 8,100-sheet max input
    • Continuous updates via RICOH Always Current Technology

    Save on future investments with our future-proofed solutions

    RICOH IM C8000, a full colour multi function printer, offers a range of smart applications, enhancements and software to manage your document needs as they change without the need to purchase new equipment. Simply install new features as needed with RICOH Always Current Technology.

    Gain even greater control of print and scan management

    The additional features you will find on RICOH IM C8000 give you so many more printing options. Scan smaller sized documents with ease with the new small-sized paper scan unit and improve scanning accuracy by simply adding an extra double feed detection unit. You can also create and print professional-grade flyers any time with our new multi-folding unit and save on outsourced printing costs.

    1. Place personalisation at your fingertips
      Perform everyday tasks with speed and precision via the large 10.1'' LCD touch screen.
    2. Convenient finishing options
      Create professional publications instantly with out high-speed duplex feeder and additional fold, staple, hole punch and booklet making options.
    3. Digitise documents for speed of access
      Scan documents at high speeds and distribute them digitally with a single touch.
    4. Add those colourful finishing touches
      Give ideas a fresh look with fast, colourful output and use the multiple finishing options available for direct mail, presentations, menus and so much more.

    Specifications

    Functions
    Copy, print, scan, optional fax
    Colour
    Yes
    HDD
    640 GB (320 GB x 2)
    Memory - standard
    4 GB
    Operation panel
    10.1-inch Smart Operation Panel (G2.5)
    Physical dimensions (WxDxH)—mainframe
    750 x 880 x 1,225 mm
    Weight—mainframe
    250 kg or less
    Standard input capacity (sheets)
    3,700
    Maximum input capacity (sheets)
    8,100
    Maximum output capacity (sheets)
    3,500
    Paper input configuration - standard
    1,250-sheet x 2 tandem tray, 2 x 550-sheet paper input trays, 100-sheet bypass tray, 220-sheet SPDF, Duplex unit
    Supported media

    Plain paper1, recycled paper, colour paper, special paper 1–3, letterhead, pre-printed paper, pre-punched paper, bond paper, card stock, thin paper, plain paper 1–2, middle thick, thick paper 1–4

    1—Not displayed as paper type

    Maximum paper size
    13" x 19.2"
    Media weight (g/m2)
    52.3–300
    Interfaces - standard
    Mainframe
    10Base-T/100Base-TX/1000Base-T (Gigabit Ethernet)
    USB Host Type A—2 ports
    USB Device Type B—1 port

    Smart Operation Panel
    IEEE 802.11 b/g/n (Wireless LAN)1
    Bluetooth 4.22
    SD Card Slot—SDHC memory card
    USB Host Type A—USB Flash memory
    USB Host Type A—1 port for USB keyboard (optional)2
    USB Host Type mini B—for NFC card reader (optional)2
    microSD card slot—ROM storage expansion2
    NFC Tag2

    1—Limited printing for a peer-to-peer mobile device via RICOH Smart Device Connector
    2—Cannot be used for printing
    Interfaces - optional

    IEEE 1284
    Wireless LAN (IEEE 802.11 a/b/g/n)1
    Device Server Option Type M37 (additional NIC port)
    Copy Connector Type M25

    1—Cannot be used with Bluetooth at the same time

    Network protocols - standard
    TCP/IP (IPv4, IPv6)
    Copy speed
    80 cpm
    First copy time
    4.8 seconds—black and white
    6.4 seconds—colour
    Copy resolution
    600 x 600 dpi
    Zoom range
    25%–400% in 1% steps
    Enlargement ratios
    400%, 200%, 141%, 122%, 115%
    Reduction ratios
    93%, 82%, 75%, 71%, 65%, 50%, 25%
    Duplex copy
    Simplex to duplex, duplex to duplex—with SPDF, book to duplex, front and back to duplex
    Book copy
    Booklet, magazine, layout, and booklet
    ID card copy
    Supported
    Print speed colour
    80 ppm
    Print speed black and white
    80 ppm
    First print time
    4.8 seconds or less—black and white; 6.4 seconds or less—colour
    Print resolution
    1,200 x 4,800 dpi—when printing
    2,400 x 4,800 dpi—when copying
    Page description languages (PDLs)

    Standard
    PCL 5c, PCL 6, PostScript3 emulation, PDF Direct emulation

    Optional
    Adobe PostScript 3, Adobe PDF Direct, XPS, IPDS

    Printer drivers

    Standard
    PCL 5c, PCL 6, PostScript3 emulation

    Optional
    Adobe PostScript 3

    Duplex printing
    Standard
    Mobile printing
    AirPrint, Mopria®, RICOH Smart Device Connector
    Print from USB/SD
    Supported
    Scan speed
    A4 LEF via SPDF
    120 ipm—simplex
    240 ipm—duplex
    Scan methods
    Scan to USB/SD, Scan to email, Scan to folder (SMB, FTP), Scan to URL, Scan to PDF/A, Scan to digitally signed PDF, Scan to searchable PDF (embedded)
    Colour scanning
    Standard
    Scan resolution
    100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi, 1,200 dpi
    Scan to file types
    Single- and multi-page TIFF
    Single-page JPEG
    Single- and multi-page PDF, PDF/A
    Single- and multi-page High-Compression PDF
    Scan to email

    Protocols
    SMTP gateway, TCP/IP

    Authentication
    SMTP authentication, POP before SMTP authentication

    Scan resolution
    100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi

    Scan to email file types
    Single-page
    TIFF, JPEG, PDF, PDF/A, High-Compression PDF, Encrypted PDF, Searchable PDF

    Multi-page
    TIFF, PDF, PDF/A, High-Compression PDF, Encrypted PDF, Searchable PDF

    Note: Optional OCR unit is required to support scanning to a searchable PDF.

    Scan to folder

    Protocols
    SMB, FTP, WSD (Web Services on Devices for Scanning), DSM

    Security
    Client folder logon, transmission encryption of logon name and password

    Resolution
    100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi

    Search for client folders
    SMB—browsing directly to the designated folder
    FTP—by folder name

    Scan to folders file types
    Single-page
    TIFF, JPEG, PDF, PDF/A, High-Compression PDF

    Multi-page
    TIFF, PDF, PDF/A, High-Compression PDF

    TWAIN scanning
    Scan mode
    Standard, Photo, OCR, Filing

    Scan resolution
    100–1,200 dpi
    Note: 1,200 dpi scanning is supported only with A5 or smaller paper size.
    Fax types
    G3 fax, Internet fax (T.37), IP fax (T.38), LAN-Fax, Paperless fax, Direct SMTP fax
    Fax circuit
    PSTN, PBX
    Fax compatibilty
    ITU-T (CCITT), G3—maximum 3 lines
    Fax modem speed
    2,400 bps–33.6 Kbps—G3, standard with automatic shift down
    Fax compression methods
    MH, MR, MMR, JBIG
    Fax resolution

    Standard mode
    200 x 100 dpi—8 x 3.85 lines/mm

    Detail mode
    200 x 200 dpi—8 x 7.7 lines/mm

    Super fine mode
    400 x 400 dpi—8 x 15.4 lines/mm
    400 x 400 dpi—16 x 15.4 lines/mm

    Note: Super fine mode is supported with the optional SAF memory.

    G3 fax transmission speed
    2 seconds approximately—JBIG, ITU-T No. 1 chart, TTI off, memory transmission
    3 seconds approximately—MMR, ITU-T No. 1 chart, TTI off, memory transmission
    Fax SAF memory capacity
    Standard—4 MB
    With optional SAF memory—60 MB
    Fax memory backup
    1 hour
    Quick dials
    2,000 numbers
    Data Overwrite Security System (DOSS) - Standard
    Yes
    Data Overwrite Security System (DOSS) - Optional
    Type M19—available for customers who require their devices to comply with ISO 15408 Common Criteria certification
    Encryption
    PDF, Secure print, WEP, WPA encryption
    Authentication password encryption
    Encryption of data sent via Scan to email and Fax forwarding (S/MIME)
    Authentication
    802.1x wired authentication
    IEEE 802.11i security (WEP, WPA)
    IPv6
    Network user authentication
    Quota setting/Account limit
    User authentication—Windows and LDAP via Kerberos, basic, user code
    User code authentication
    Wi-Fi Protected Setup (WPS) support
    Windows
    Windows 7
    Windows Server 2008
    Windows Server 2008 R2
    Windows 8.1
    Windows Server 2012
    Windows Server 2012 R2
    Windows 10
    Windows Server 2016
    Windows Server 2019
    Macintosh
    OS X Native v10.12 or later—PostScript 3 only
    Unix
    Sun Solaris—10
    HP-UX—11.x, 11iv2, 11iv3
    Red Hat Linux—Enterprise v4, v5, v6
    SCO OpenServer—5.0.7, 6.0
    IBM AIX—6.1, 7.1, 7.2
    SAP
    Environment—R/3, S/4
    Platform—SAP R/3 (Release versions 3.0 and higher), SAP R/3 Enterprise, mySAP ERP (2004 and higher), SAP HANA
    Page Description Language (PDL)—PCL
    Character set—Latin-1, Latin-2, Unicode
    Barcode fonts—Code 128, Code 39, Code 93, Codabar, 2 of 5 interleaved/Industrial/Matrix, MSI, USPS Postnet, UPC/EAN
    OCR fonts—OCR A, OCR B
    Other supported features—Input/Output Bin, Duplex, Stapling, Punching, Resolution, Collation, EconoMode / TonerSaving, Smoothing, Page Protect, Auto Tray Change/Optional Tray Select, User Authentication
    Standard
    @Remote Embedded
    Web Image Monitor
    Optional
    @Remote Office
    @Remote Enterprise Pro
    Global Scan NX
    Card Authentication Package
    Enhanced Locked Print NX
    Device Manager NX Lite
    Device Manager NX Accounting
    RICOH Streamline NX
    Mobile apps
    RICOH Smart Device Connector
    Power source
    220–240 V, 12–10 A, 50/60 Hz
    Power consumption
    2,400 W or less—maximum power
    1,324.7 W or less—operating power, black and white
    1,473.7 W or less—operating power, colour
    191.45 W—Ready Mode
    170 W—Low Power Mode
    0.74 W—Energy Saver Mode (Sleep Mode)
    Typical Electricity Consumption (TEC)
    1.651 kWh (nominal), 2.049 kWh (guaranteed)
    Warm-up time
    40 seconds
    Power saving mode
    45 minutes shift time—Energy Saver Mode (Sleep Mode)
    15 minutes shift time—Low Power Mode
    Recovery time
    38 seconds—Energy Save Mode (Sleep Mode)
    7.9 seconds—Low Power Mode
    Other environmental features
    Eco-friendly indicator screen, System reset timer
